FolkPatch provides a lightweight Lua plugin system. Plugins are an extension form sitting between APM and KPM: they do not modify system files or inject into the kernel — they only run Lua callbacks within the apd daemon lifecycle.

Plugins are built on mlua (Lua 5.4) and run with root privileges, suitable for lightweight automation scripts such as scheduled tasks, property tuning, and cache cleaning.

• Plugin vs vs
• Plugin Package Format
• Manifest plugin.json
• Entry Script main.lua
• Plugin API
  • exec Example
• Action Operation
• User Configuration
• Scheduled Loop Events
  • 1. Declare a main Callback (Recommended)
  • 2. start_daemon
  • Stopping the Daemon
• Lifecycle & State
• Management Commands
• Plugin Management Page
• Online Plugins
• Example Plugins
• Full Example: boot-script

Security Notice

Lua plugins run with root privileges, and the full Lua standard library is available (arbitrary command execution, arbitrary file read/write). Only install plugins from trusted sources and always review the code before installing.

Plugin vs APM vs KPM

Aspect	APM	Lua Plugin	KPM
Runtime space	Userspace	Userspace (inside apd)	Kernel space
Modifies system files	Yes (mount)	No	No
Kernel injection	No	No	Yes
Language	Shell / any	Lua	C
Typical use	System-level modification, file replacement	Scheduled tasks, property tuning, automation	Kernel hooks, low-level customization
Risk level	Medium	Medium	High

Plugin Package Format

Plugins are installed as a zip package or a directory, located at /data/adb/plugins/<id>/ after installation. Zip structure:

my-plugin.zip

plugin.json# Manifest (required, declares metadata and dependencies)

main.lua# Entry script (required, or specified by manifest entry)

Directory Detection

Files inside the zip can be placed at the root or in a single top-level directory; the installer automatically detects the directory containing the entry file and extracts it.

Manifest plugin.json

plugin.json declares the plugin's metadata, dependencies, entry, and configuration fields:

{
  "id": "my-plugin",
  "name": "My Plugin",
  "author": "your-name",
  "version": "1.0.0",
  "description": "What this plugin does",
  "descriptions": { "zh": "插件功能描述", "ja": "プラグインの説明" },
  "license": "MIT",
  "min_version": 0,
  "depends": ["another-plugin"],
  "entry": "main.lua",
  "config": [],
  "quick_action": null
}

idRequiredstring

Plugin identifier. Must match the directory name; only alphanumerics and -_. are allowed.

nameOptionalstring

Display name; falls back to id if omitted.

authorOptionalstring

Author.

versionOptionalstring

Version.

descriptionOptionalstring

Description.

descriptionsOptionalobject

Localized descriptions keyed by language code (e.g. zh, ja, tr).

licenseOptionalstring

License.

min_versionOptionalnumber

Minimum required APD version code (number). Validated at install time; installation is rejected if the current version is lower.

dependsOptionalstring[]

List of other plugin ids this plugin depends on. Validated at both install and runtime (missing or disabled dependencies cause errors).

entryOptionalstring

Entry Lua file; defaults to main.lua. Path separators and .. are not allowed.

configOptionalConfigField[]

Declared configuration fields shown in the manager UI. See User Configuration.

quick_actionOptionalQuickAction

Quick action: a one-tap button in the manager UI that runs a specified callback. See Action Operation.

Entry Script main.lua

main.lua must return a Lua table, optionally declaring lifecycle callbacks:

return {
    post_fs_data = function()
        info("plugin loaded")
    end,
    post_mount = function()
        -- after modules are mounted
    end,
    service = function()
        -- service phase is suitable for lightweight background initialization
    end,
    boot_completed = function()
        -- after Android boot is complete
    end,
}

Callback	Trigger
post_fs_data	post-fs-data phase (blocking, before module mount)
post_mount	after modules are mounted
service	late_start service phase (non-blocking, recommended)
boot_completed	after Android boot is complete
main	Special callback, runs as a background daemon loop. See Scheduled Loop
action	Special callback for manual triggering. See Action Operation

The runtime environment provides the following globals:

• PLUGIN_ID: current plugin identifier
• PLUGIN_DIR: current plugin directory (e.g. /data/adb/plugins/my-plugin)

Logs from info() / warn() are appended to last_output.log in the plugin directory.

Plugin API

In addition to the Lua standard library, the plugin runtime provides the following functions:

Function	Description
getprop(name)	Read a system property, returns a string
setprop(name, value)	Set a system property (bypasses read-only), returns boolean
sysctl(key, value)	Write a kernel parameter (e.g. sysctl("vm.swappiness", "60")), returns boolean

Function	Description
exec(...)	Run a command, returns a { ok, code, stdout, stderr } table. Use exec("cmd", "arg") or exec("sh", "-c", "...")

Function	Description
write_file(path, content)	Write a text file (auto-creates parent dirs), returns boolean
read_file(path)	Read file content, returns a string
list_dir(path)	List directory entries, returns an array table of names
file_exists(path)	Check whether a path exists (file or directory), returns boolean
chmod(path, mode)	Set permissions (number or string, e.g. 0755 or "0755"), returns boolean
mkdir(path, recursive)	Create a directory; recursive when recursive is true, returns boolean
rm(path)	Remove a file or empty directory, returns boolean

Function	Description
json_decode(str)	Parse a JSON string into a Lua value
json_encode(value)	Serialize a Lua value to a JSON string

Function	Description
get_config(key)	Read this plugin's saved user config value (string)
set_config(key, value)	Save a user config value for this plugin, returns boolean
info(msg)	Output an info log
warn(msg)	Output a warning log

Function	Description
start_daemon(function, interval_secs)	Spawn the named callback as a background daemon, looping every interval_secs seconds, returns boolean

exec Example

local result = exec("sh", "-c", "df -h /data")
if result.ok then
    info("stdout: " .. result.stdout)
else
    warn("failed, code=" .. result.code .. ", stderr=" .. result.stderr)
end

Action Operation

A plugin can declare an action callback, which shows a "Run" button in the manager UI for manually executing an operation (e.g. manual cache clean):

return {
    action = function()
        -- manually triggered operation logic
        info("manual clean triggered")
    end,
}

Trigger from the command line:

apd plugin action <id>

You can also declare the button label via quick_action in plugin.json:

{
  "quick_action": {
    "function": "clean_now",
    "label": "Clean Now",
    "labels": { "zh": "立即清理", "ja": "今すぐクリーン" }
  }
}

User Configuration

A plugin can declare configuration fields in plugin.json. The manager UI shows a "Config" button that opens an editor; configuration is saved to /data/adb/plugins/<id>/config.json:

{
  "id": "my-plugin",
  "config": [
    { "key": "clean_hour", "label": "Cleaning hour (0-23)", "labels": { "zh": "清理时间" }, "type": "number", "default": 4 },
    { "key": "clear_all", "label": "Also clear running app caches", "labels": { "zh": "同时清理运行中应用缓存" }, "type": "bool", "default": false },
    { "key": "mode", "label": "Mode", "type": "select", "options": ["auto", "manual"] }
  ]
}

keyRequiredstring

Config key, used by get_config / set_config.

labelOptionalstring

Human-readable label (default / English).

labelsOptionalobject

Localized labels keyed by language code.

typeOptionalstring

text

Field type: text / number / bool / select.

defaultOptionalany

Default value.

optionsOptionalstring[]

Options for the select type.

Inside the plugin, use get_config / set_config to read and write config. Command line:

apd plugin config --id my-plugin list
apd plugin config --id my-plugin get clean_hour
apd plugin config --id my-plugin set clean_hour 3
apd plugin config --id my-plugin delete clean_hour

Scheduled Loop Events

Plugins support two scheduled loop approaches:

1. Declare a main Callback (Recommended)

If the returned table contains a main function, the system automatically spawns it as a background daemon during the service phase, looping continuously (default interval 1 second; you can sleep inside the loop to control the pace):

return {
    main = function()
        while true do
            -- check every minute
            if os.time() % 60 == 0 then
                info("tick")
            end
            os.execute("sleep 30")
        end
    end,
}

The main daemon runs independently of the apd boot sequence — it does not block other plugins and does not exit with a single phase invocation.

2. start_daemon

Manually spawn a background loop inside any callback:

return {
    service = function()
        start_daemon("main", 60)  -- call this plugin's main every 60 seconds
    end,
    main = function()
        -- scheduled task logic
    end,
}

Stopping the Daemon

After disabling the plugin (apd plugin disable <id>) and rebooting, the daemon will no longer start; an already-running daemon can be terminated with kill.

Manually test a scheduled loop:

apd plugin daemon <id> <function> <interval_secs>

Lifecycle & State

• Create an empty disable file to disable a plugin; delete it to re-enable
• Plugins are automatically executed by apd in the post-fs-data, post-mount, service, and boot-completed phases
• An error in a single plugin is logged and does not affect other plugins

Management Commands

apd plugin list                          # List plugins (JSON, with metadata, action, config)
apd plugin install <zip>                 # Install from zip
apd plugin uninstall <id>                # Uninstall
apd plugin enable <id>                   # Enable
apd plugin disable <id>                  # Disable
apd plugin run <id> <function>           # Manually run a callback
apd plugin action <id>                   # Run the plugin's action callback
apd plugin daemon <id> <function> <secs> # Run a callback as a looping daemon
apd plugin config --id <id> ...          # View/modify plugin config (list/get/set/delete)

Plugin Management Page

The plugin management entry is located in the top bar of the Settings page. The page provides:

• Enable / Disable toggle: switch plugin state (corresponds to creating/removing the disable file)
• Run: manually trigger the plugin's action callback (or the quick_action declared in the manifest)
• Config: edit the plugin's declared configuration fields
• Execution Output: view the plugin's last_output.log, with export and clear support
• Uninstall: remove the plugin
• Online Plugins: browse and download plugins from the official plugin repository. See Online Plugins

Online Plugins

The plugin management page has a built-in Online Plugins feature that lets you browse and install plugins from the official FolkPatch plugin repository:

• Search plugins by name / description
• Automatic Chinese/English description switching
• Track download progress via the notification bar, then install from the plugin page after download completes

注意

Online plugins also run with root privileges. Verify the plugin's source and feature description before downloading.

Example Plugins

The FolkPatch repository ships five ready-made examples in the examples/plugins/ directory:

• boot-script/: a boot script plugin that runs custom commands at a chosen boot stage, with support for waiting on a path and manual immediate execution
• cache-cleaner/: a scheduled cache cleaner plugin that automatically cleans app and system caches in the early hours each day
• hello-plugin/: demonstrates basic APIs such as getprop, setprop, exec, and file I/O
• file-tick-test/: a file operation and scheduled loop test plugin
• log-rotator/: a log rotation plugin

Scheduled cache cleaner usage example:

apd plugin install /path/to/cache-cleaner.zip   # or place it in the directory directly
apd plugin run cache-cleaner clean_now          # manually clean once right away
apd plugin action cache-cleaner                 # or tap the "Run" button in the manager

Configuration fields are edited via the "Config" button in the manager (cleaning hour, whether to clear running app caches), or by editing config.json directly. The plugin declares action and main callbacks: action for manual triggering, main running automatically as a background daemon after boot.

Full Example: boot-script

Below is the complete source of the official boot-script example plugin, demonstrating the comprehensive use of manifest declaration, configuration fields, multi-stage lifecycle, quick_action, and API calls: it runs custom commands at the user-selected boot stage, optionally waiting for a path to become ready first.

plugin.json

main.lua

plugin.json

{
  "id": "boot-script",
  "name": "Boot Script",
  "author": "FolkPatch",
  "version": "1.1.0",
  "description": "Run custom commands at a chosen boot stage",
  "descriptions": {
    "zh": "在指定的启动阶段执行自定义命令",
    "ja": "指定した起動段階でカスタムコマンドを実行"
  },
  "license": "MIT",
  "quick_action": {
    "function": "run_now",
    "label": "Run now",
    "labels": { "zh": "立即执行", "ja": "今すぐ実行" }
  },
  "config": [
    {
      "key": "stage",
      "label": "Execution stage",
      "labels": { "zh": "执行时机" },
      "type": "select",
      "options": ["post_fs_data", "service", "boot_completed"],
      "default": "boot_completed"
    },
    {
      "key": "wait_path",
      "label": "Path to wait for (empty = off)",
      "labels": { "zh": "等待就绪的路径（留空=关闭）" },
      "type": "text",
      "default": "/sdcard"
    },
    {
      "key": "wait_time",
      "label": "Wait timeout (seconds, 0 = off)",
      "labels": { "zh": "等待超时（秒，0=关闭）" },
      "type": "number",
      "default": 0
    },
    {
      "key": "commands",
      "label": "Commands (one per line)",
      "labels": { "zh": "命令列表（每行一条）" },
      "type": "text",
      "default": ""
    }
  ]
}

main.lua

local M = {}

-- Wait up to N seconds for a path to become ready (e.g. /sdcard after unlock)
local function wait_for_path(path, timeout_sec)
    local waited = 0
    while waited < timeout_sec do
        local r = exec("test", "-d", path)
        if r.ok then
            info("Path ready after " .. waited .. "s: " .. path)
            return true
        end
        exec("sleep", "1")
        waited = waited + 1
    end
    warn("Timeout waiting for path (" .. timeout_sec .. "s): " .. path)
    return false
end

local function run_commands()
    local cmds = get_config("commands")
    if cmds == "" then
        info("No commands configured")
        return
    end
    for line in cmds:gmatch("[^\n]+") do
        line = line:match("^%s*(.-)%s*$")
        if line ~= "" and line:sub(1, 1) ~= "#" then
            info("Running: " .. line)
            local r = exec("sh", "-c", line)
            if r.ok then
                if r.stdout ~= "" then info("  stdout: " .. r.stdout) end
            else
                warn("  failed (code " .. r.code .. "): " .. r.stderr)
            end
        end
    end
    info("All commands executed")
end

local function try_run(stage)
    local target = get_config("stage")
    if target == "" then target = "boot_completed" end
    if stage == target then
        info("Stage [" .. stage .. "] matched, executing...")
        -- If configured, wait for a path to be ready first
        local wait_path = get_config("wait_path")
        local wait_time = tonumber(get_config("wait_time")) or 0
        if wait_path ~= "" and wait_time > 0 then
            wait_for_path(wait_path, wait_time)
        end
        run_commands()
    end
end

function M.post_fs_data()
    try_run("post_fs_data")
end

function M.service()
    try_run("service")
end

function M.boot_completed()
    try_run("boot_completed")
end

-- Quick action: run manually regardless of stage
function M.run_now()
    run_commands()
end

return M

Key Points

• The manifest declares 4 configuration fields (execution stage, wait path, wait timeout, command list), editable via the "Config" button in the manager
• quick_action declares a "Run now" button bound to the run_now callback, allowing manual triggering at any time
• main.lua declares three lifecycle callbacks (post_fs_data / service / boot_completed); try_run checks whether the current stage matches the configured stage and only executes when it matches
• Uses APIs such as exec, get_config, info, and warn

Copyright

Copyright Ownership:FolkPatch Team

License under:Attribution 4.0 International (CC-BY-4.0)

Edit this page

Contributors: matsuzaka-yuki

Previous pageKernelPatch Module

Next pageTheme Preview & Use
